KF NW VCR Adaptor
KF NW 16-50 VCR Male Adaptor
KF NW VCR Male Adaptor
KF NW VCR Male Adaptor
‧材質： Stainless Steel / S.S.304
Part Number
Model Size
A
B
C
Male VCR
我要詢價
KF16MVCR6
KF NW 16
30
1.181
4.4
0.173
43.2
1.700
1/4”
1/4”
KF25MVCR6
KF NW 25
40
1.575
4.4
0.173
43.2
1.700
1/4”
1/4”
KF40MVCR6
KF NW 40
55
2.165
4.4
0.173
43.2
1.700
1/4”
1/4”
KF50MVCR6
KF NW 50
75
2.953
4.4
0.173
43.2
1.700
1/4”
1/4”
注意:
‧如無特別標示單位, 所有尺寸皆為
公制 (mm)
.
‧FVAC 保留修改產品設計與規範之權利來提升產品品質.
