CF16-350 (Conflat Flange) Bored Flange-Nonrotatable
CF (Conflat Flange) Bored-Nonrotatable
CF (Conflat Flange) Bored-Nonrotatable
‧材質： Stainless Steel / S.S.304
Part Number
Model Size
A
B
C*No.
D
P.C.D
我要詢價
CF16B19
1-1/3" (CF 16)
33.8
1.331
7.5
0.295
4.4*6
0.173*6
19.3
0.760
26.9
1.059
CF35B38
2-3/4" (CF 35)
69.5
2.736
12.7
0.500
6.7*6
0.264*6
38.3
1.508
58.7
2.311
CF35B43
69.5
2.736
12.7
0.500
6.7*6
0.264*6
42.9
1.689
58.7
2.311
CF63B64
4-1/2" (CF 63)
113.6
4.472
18
0.709
8.4*8
0.331*8
63.7
2.508
92.1
3.626
CF100B102
6" (CF 100)
151.6
5.969
20
0.787
8.4*16
0.331*16
101.8
4.008
130.3
5.130
CF150B153
8" (CF 150)
202.5
7.972
22
0.866
8.4*20
0.331*20
152.8
6.016
181
7.126
CF200B204
10" (CF 200)
253.2
9.969
24.7
0.972
8.4*24
0.331*24
203.7
8.020
231.8
9.126
CF250B254
13-1/4" (CF 250)
336.5
13.248
28.5
1.122
10.3*30
0.406*30
254.5
10.020
306.5
12.067
CF300B305
14" (CF 300)
355.6
14.000
28.5
1.122
10.3*30
0.406*30
305.4
12.024
325.7
12.823
CF350B356
16-1/2" (CF 350)
419.1
16.500
28.5
1.122
10.3*36
0.406*36
356.1
14.020
388.9
15.311
注意:
‧如無特別標示單位, 所有尺寸皆為
公制 (mm)
.
‧FVAC 保留修改產品設計與規範之權利來提升產品品質.
